2000.2 EVO 5
The 2000.2 EVO 5 is a compact, modern amplifier that delivers 2000W RMS of power distributed over 2 channels.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
Available in:
Instruction manualGeneral Specifications
+
-
2000.2 EVO 5 – 2 OHMS
Power @ 1Ω: 2 X 1000W
Power @ 2Ω: 2 X 660W
Bridge Power @ 2Ω: 1 X 2000W
Bridge Power @ 4Ω: 1 X 1320W2000.2 EVO 5 – 4 OHMS
Power @ 1Ω: N/A
Power @ 2Ω: 2 X 1000W
Bridge Power @ 2Ω: N/A
Bridge Power @ 4Ω: 1 X 1200WFrequency Response (-3dB):
10Hz ~ 20kHz
Low Pass Filter (LP -12dB/8):
80Hz
High Pass Filter (HP -12dB/8):
80Hz
Operating Voltage:
8V ~ 16V
SNR:
90dB
Input Sensitivity:
0.2 ~ 2V
Current Draw (Music):
2Ω: 89A
4Ω: 88ACurrent Draw With Resistive Load (1kHz @ 12.6V):
2Ω: 178A
4Ω: 176ATotal Efficiency:
2Ω: 89%
4Ω: 90%Damping Factor (@100Hz Rated Impedance):
200
Minimum Audio Output Impedance:
2Ω: 1 ohm
4Ω: 2 ohmsMinimum Bridge Impedance:
2Ω: 2 ohm
4Ω: 4 ohmsRecommended Fuse (Music):
100A
Recommended Battery (Music):
100Ah
Width:
5.4 in / 13,6 cm
Length:
8.9 in / 22,8 cm
Height:
2.2 in / 5,5 cm
Weight:
3.39 lb / 1,58 Kg
